Figure -
Assembling the Mounting Screws and Spring Washers to the OmniAccess AP 1200 or 1250
•
Copy the MAC address(es) from the label(s) on the OmniAccess AP 1200 or 1250 onto the
corresponding location on the map. MAC addresses have the format 000B85xxxxxx.
•
You have already attached the flush-mount bracket to the wall in
Locations.
•
Slide the screws into the keyhole slots on the mounting bracket as shown in the following
figure.
Note:
away from the wall. This ensures that the correct antenna is facing the building, and
makes future upgrades easier.
Note:
1200 or 1250 and adjust the screws until they securely hold the bracket.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 16
Make sure the side of the OmniAccess AP 1200 or 1250 with the door is facing
If the screws do not securely hold the bracket, remove the OmniAccess AP
Step 4: Mounting the OmniAccess AP Access Points
Step 3: Preparing Mounting
