Table -
General (Continued)
Severity
Previous Severity
•
Annotations: Use this text box to type notes about this rogue access point radio, then click
Add.
•
Message: Displays descriptive information about the alarm.
•
Help: Displays information about the alarm.
•
Event History: Displays alarm history.
•
Annotations: Lists existing rogue access point notes.
Select a command
•
Assign to me: Assigns this alarm to the user.
•
Unassign: Unassigns this alarm from the user.
•
Delete: Deletes the displayed alarm.
•
Event History: Refer to
•
Detecting APs: Refer to
•
Map (High Resolution): For High resolution Heat Maps, you must have ACS Location
(High-Resolution) Software or WPS Location Software installed. Low Resolution Heat Maps are
enabled for ACS Basic (Low-Resolution) Software or WPS Basic Software.
•
Trend: Refer to
•
Rogue Clients: Tells ACS to display
•
Set State to "Unknown - Alert": Sets the alarm state as indicated.
•
Set State to "Known-Internal": Sets the alarm state as indicated.
•
Set State to "Know-External": Sets the alarm state as indicated.
•
Level 1 Containment, Level 2 Containment, Level 3 Containment, Level 4 Containment: This
feature allows the administrator to target a rogue access point for containment. An AP which is
being contained will either not be able to provide service at all, or will provide exceedingly slow
service. There is a level associated with the containment activity which indicates how many
OmniAccess AP Access Points to use in containing the threat. Note that this service must be
initiated and halted by the administrator.

Monitor RF Calibration Models

Use Monitor/Maps, then select RF Calibration Models and click GO to access this page.
This page allows you to view the current calibrated and uncalibrated RF Calibration Models.
The Calibration Models are used as RF overlays with measured RF signal characteristics that can be
applied to different floor areas. This allows the Alcatel OmniAccess Wireless System installation team to
lay out one floor in a multi-floor area, use the RF Calibration tool to measure and save the RF charac-
teristics of that floor as a new calibration model, and apply that calibration model to all the other floors
with the same physical layout.
The resulting RF Calibration Models make client and rogue AP location much more precise when using
the Alcatel OmniAccess Control System Location Software.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 41
Level of severity, Critical, Major, Minor, Warning, Clear, Info. Color coded.
Critical, Major, Minor, Warning, Clear, Info. Color coded.
Monitor Rogue Alarm >
Monitor Alarms > Rogue AP <MACaddress> > Detecting
Monitor Alarms > Rogue AP <MACaddr>
Monitor Clients Associated with Rogue AP
Monitor RF Calibration Models
Events.
Trend.
Monitor RF Calibration Models
APs.
<MACaddr>.
