Configure <IPaddr> > WPS Group <name> > Group Members
Use CONFIGURE/Switches and click an IP address under the IP Address column, on the left sidebar
menu, select System and click WPS Peers to access this page.
Note that this command is only supported in the Standalone WPS Alcatel OmniAccess Wireless System
described in About the Alcatel OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product
Guide.
This page allows you to view, add or delete WPS group members.
•
Checkbox: Use this to select a group member.
•
Switch Name: User-defined Alcatel OmniAccess Switch or Appliance name.
•
Member MAC Address: MAC address of the WPS group member.
•
Member IP Address: DS Port IP Address of the WPS group member.
Select a command
•
Add Group Members: Select this command and click GO. Refer to
Group <name>.
•
Delete Group Members: To delete a group member, highlight a checkbox, select this command,
and click GO.

Configure WLAN

Configure WLAN
Use CONFIGURE/Switches and click WLANs to access this page.
Note that the Standalone WPS Alcatel OmniAccess Wireless System described in About the Alcatel
OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product Guide does not support
WLANs.
This page allows you to view a summary of the wireless local access networks (WLANs) that you have
configured on your network. From this page, you may add, delete or edit WLANs.
Table -
WLANs
Parameter
Checkbox
WLAN ID
SSID
Security Policies
Admin Status
Select a command pulldown
•
Add WLAN: Refer to
•
Delete WLANs: Select one or more WLANs to delete by selecting their checkboxes, then select
this command and click GO.
11/5/04 Configure <IPaddr> > WPS Group <name> > Group Members
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 67
Use this checkbox to select a WLAN to delete.
Identification number of the WLAN. Refer to
> <WLAN ID> (name).
Service Set Identifier being broadcast by the WLAN.
Security policies enabled on the WLAN.
Status of the WLAN is either enabled or disabled.
Configure <IPaddr> > WLAN > Add From
Configure <IPaddr> > WPS Group <name> > Group Members
Configure <IPaddr> > WPS
Description
Configure <IPaddr> > WLANs
Template.
