Recording Data with the Site Survey Tool

Use the following topics for this activity:
•

Starting to Work with the Site Survey Tool

•
Recording a Site Survey with Map
•
Recording a Site Survey without Map
•
Signals Tab
•
Record Tab
•
Survey Properties
•
Marking Exact Access Point Locations
•
Access Point Properties
Starting to Work with the Site Survey Tool
1.
Open the Site Survey Tool by selecting the Site Survey Tool icon in the Start > Programs >
Alcatel > Site Survey 1.0 > Alcatel Site Survey. This will automatically launch Alcatel Client
service that reads WLAN information from your adapter.
2.
Make sure that Alcatel Client runs properly by clicking the blue icon in the Windows task bar:
3.
If you cannot see the icon, start Alcatel Client from Start > Programs > Alcatel > Client
Controller.
4.
After the Site Survey Tool has started, click the Signals tab in the lower part of the screen. If
you can't see changing signal values, make sure that Alcatel Client is running, and your adapter
and driver version are supported (see
The figure below shows the Site Survey Tool startup screen with the signals tab opened in the bottom
view.
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 17
Recording Data with the Site Survey Tool
Starting to Work with the Site Survey Tool
Getting Started).
