Alcatel OmniAccess Wireless System 2.1 Product Manual page 655

Table -
General (Continued)
Parameter
Channel
Power Level
Switch
Port
Map Location
Profile Information
•
Noise Profile: Notification sent when Noise Profile state changes between Okay and Fail.
•
Interference Profile: Notification sent when Interference Profile state changes between Okay
and Fail.
•
Load Profile: Notification sent when Load Profile state changes between Okay and Fail. Note
that the Standalone WPS Alcatel OmniAccess Wireless System described in About the Alcatel
OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product Guide does not
support voice or data client load balancing.
•
Coverage Profile: Notification sent when Coverage Profile state changes between Okay and Fail.
Note that the Standalone WPS Alcatel OmniAccess Wireless System described in About the
Alcatel OmniAccess Wireless System in the Alcatel OmniAccess Wireless Product Guide does not
support voice or data client coverage.
Noise by Channel (dBm)
Graph showing channel and noise.
Interference by Channel (dBm%)
Graph showing the percentage of interference per channel.
Load Statistics
•
RX Utilization: 802.11a or 802.11b/g RF receive utilization threshold between 0 and
100 percent.
•
TX Utilization: 802.11a or 802.11b/g RF transmit utilization threshold between 0 and
100 percent.
•
Channel Utilization: 802.11a RF utilization threshold between 0 and 100 percent (Subcolumns
for Actual and Threshold).
11/5/04
90-100831-300 Rev 2Alcatel OmniAccess Wireless Access Point Quick Installation Guide 76
The channel upon which the OmniAccess Radio is broadcasting.
OmniAccess AP 1200 or 1250 transmit power level (1 = Maximum power
allowed per Country Code setting, 2 = 50% power, 3 = 25% power, 4 =
12.5% power, and 5 = 6.25% power). The power levels and available
channels are defined by the Country Code setting, and are regulated on a
country by country basis. Refer to Supported Regulatory Domains in the
Alcatel OmniAccess Wireless Product Guide for the maximum Transmit
Power Levels for each country.
IP Address of Alcatel OmniAccess Switch or Appliance. Click to display
Monitor Switches > <IPaddr> >
(1 to 24) Port to which the OmniAccess AP 1200 or 1250 is connected.
Click to display the floor map showing the OmniAccess AP 1200 or 1250
location. Refer to Monitor Maps > <campus> > <building> > <floor
area>.
Monitor Access Points > <name> > <radio type>
Description
Summary.
