Hash Table Algorithm
In the physical type of address recognition, the Ethernet controller compares the destination
address field of the received frame with the physical address that the user programs in the
PADDR. If it fails, the controller performs address recognition on multiple individual
addresses using the IADDR_H/L hash table. Since the controller always checks PADDR
and the individual hash, for individual address the user must write zeros to the hash in order
to avoid a hash match and ones to PADDR in order to avoid individual address match.
In the group type of address recognition, the Ethernet controller determines whether the
group address is a broadcast address. If it is a broadcast and broadcast addresses are
enabled, the frame is accepted. If the group address is not a broadcast address, the user can
perform address recognition on multiple group addresses using the GADDR_H/L hash
table. In promiscuous mode, the Ethernet controller receives all of the incoming frames
regardless of their address when an external CAM is not used.
If an external CAM is used for address recognition (FPSMR[CAM] = 1), the user should
select promiscuous mode; the frame can be rejected if there is no match in the CAM. If the
on-chip address recognition functions detect a match, the external CAM is not accessed.
Otherwise, the CPM issues a match transaction to the CAM using the bus on which the data
buffers reside. (The data buffer bus is selected in FCRx[DTB]; see Section 30.7.1, "FCC
Function Code Registers (FCRx).") Note that even if the CAM is placed on the local bus
and the data buffers are on the 60x bus, match transactions are eventually accessed
correctly. That is, the CPM attempts to access the CAM on the 60x bus, but the
60x-to-local-bus bridge logic detects the 60x bus transaction and forwards it to the CAM
on the local bus.
36.13 Hash Table Algorithm
The hash table process used in the individual and group hash filtering operates as follows.
The Ethernet controller maps any 48-bit address into one of 64 bins, which are represented
by the 64 bits in GADDR_H/L or IADDR_H/L. When the command
SET GROUP ADDRESS
is executed, the Ethernet controller maps the selected 48-bit address in TADDR into one of
the 64 bits. This is performed by passing the 48-bit address through the on-chip 32-bit CRC
generator and using 6 bits of the CRC-encoded result to generate a number between 1 and
64. Bit 26 of the CRC result selects which address filter registers are used in the hashing
process—either GADDR_H/IADDR_H or GADDR_L/IADDR_L— and bits 27–31 of the
CRC result select which bit is set.
The same process is used when the Ethernet controller receives a frame. If the CRC
generator selects a bit that is set in the group/individual hash table, the frame is accepted;
otherwise, it is rejected. The result is that if eight group addresses are stored in the hash
table and random group addresses are received, the hash table prevents roughly 56/64
(87.5%) of the group address frames from reaching memory. The core must further filter
those that reach memory to determine if they contain one of the eight preferred addresses.
