Bit 31 TEXTEN: Extended clock timeout enable
Bits 30:28 Reserved, must be kept at reset value.
Bits 27:16 TIMEOUTB[11:0]: Bus timeout B
Note: These bits can be written only when TEXTEN = 0.
Bit 15 TIMOUTEN: Clock timeout enable
Bits 14:13 Reserved, must be kept at reset value.
Bit 12 TIDLE: Idle clock timeout detection
Note: This bit can be written only when TIMOUTEN = 0.
Bits 11:0 TIMEOUTA[11:0]: Bus Timeout A
Note: These bits can be written only when TIMOUTEN = 0.
Note:
If the SMBus feature is not supported,
"0x00000000".
34.7.7
I2C interrupt and status register (I2C_ISR)
Address offset: 0x18
Reset value: 0x0000 0001
Access: No wait states
31
30
29
Res.
Res.
Res.
Res.
15
14
13
TIME
BUSY
Res.
ALERT
OUT
r
r
0: Extended clock timeout detection is disabled
1: Extended clock timeout detection is enabled. When a cumulative SCL stretch for more
than t
is done by the I2C interface, a timeout error is detected (TIMEOUT = 1).
LOW:EXT
This field is used to configure the cumulative clock extension timeout:
In master mode, the master cumulative clock low extend time (t
In slave mode, the slave cumulative clock low extend time (t
t
= (TIMEOUTB + TIDLE = 01) x 2048 x t
LOW:EXT
0: SCL timeout detection is disabled
1: SCL timeout detection is enabled: when SCL is low for more than t
high for more than t
IDLE
0: TIMEOUTA is used to detect SCL low timeout
1: TIMEOUTA is used to detect both SCL and SDA high timeout (bus idle condition)
This field is used to configure:
The SCL low timeout condition t
t
= (TIMEOUTA + 1) x 2048 x t
TIMEOUT
The bus idle condition (both SCL and SDA high) when TIDLE = 1
t
= (TIMEOUTA + 1) x 4 x t
IDLE
Refer to
Section
28
27
26
25
Res.
Res.
Res.
12
11
10
9
PEC
OVR
ARLO
ERR
r
r
r
r
(TIDLE = 1), a timeout error is detected (TIMEOUT = 1).
when TIDLE = 0
TIMEOUT
I2CCLK
I2CCLK
this register is reserved and forced by hardware to
34.3.
24
23
22
Res.
r
r
8
7
6
BERR
TCR
TC
r
r
r
RM0453 Rev 5
Inter-integrated circuit (I2C) interface
LOW:MEXT
) is detected
LOW:SEXT
I2CCLK
TIMEOUT
21
20
19
ADDCODE[6:0]
r
r
r
5
4
3
STOPF NACKF ADDR
RXNE
r
r
r
) is detected
(TIDLE = 0) or
18
17
16
DIR
r
r
r
2
1
0
TXIS
TXE
r
rs
rs
1107/1450
