PTSE Table Parameters
Table 58 through Table 63 describe the parameters displayed in the PTSE
table. For clarity, the information has been divided into different sections:
Table 58 PTSE Table Parameters - PTSE Section
Parameter

Level #

Node #
Node Id
ATM Address
MAC Address
PTSE Id.
Length
Type
Seq. no.
CkSum
Lifetime
Description
Table 59 PTSE Table Parameters - Node Topology Link Section
Parameter
Node #
Node Id
ATM Address
MAC Address
Showing PNNI Information
Description
Hierarchical level.
The number of the node.
The node id in hex (22 bytes).
The ATM address of the node (19 bytes).
The MAC address of the node (6 bytes)
The PTSE id.
The length of the PTSE in bytes.
PTSE type. This may be one of the following:
96 - Nodal state parameters
97 - Nodal information group
224 - Internal reachable ATM addresses
256 - Exterior reachable ATM addresses
288 - Horizontal links
289 - Uplinks
640 - System Capabilities
PTSE sequence number.
Checksum. The PTSE checksum includes the logical
node ID and the Originating Node's Peer Group ID
from the PTSP header as well as the entire contents of
the PTSE (including the PTSE header), and excludes the
PTSE remaining lifetime.
The remaining lifetime of the PTSE (in tenths of a
second)
A brief description of the type of PTSE. See the Type
parameter above for the full list of types.
Description
The number of the node.
The node id in hex.
The ATM address of the node.
The MAC address of the node.
447
