C 1: O
28
HAPTER VERVIEW
CoreBuilder 7000HD
Switch
Interfaces to Ethernet and Fast Ethernet
Up to four interface cards of the following types can be inserted into the
CoreBuilder 7000 chassis and supported simultaneously:
Table 6 Interfaces to Ethernet and Fast Ethernet
Interface Card
4-Port ATM Interface
Card
7200 ATM/Ethernet
Interface Card
7400 High Density
ATM/Ethernet Interface
Card
7600 Fast Ethernet Card 8/16 100Base-TX or 100Base-FX connections
7800 Gigabit Ethernet
Card
7900 High Density
10/100 Ethernet Card *
* This new interface card will be available in September 1999. For more details about the 7900
consult your 3Com Representative.
The CoreBuilder 7000HD switch supports demanding enterprise
backbones and high-density data center applications, providing
high-performance ATM switching at both the network core and
boundary. The CoreBuilder 7000HD platform features a 5.0 Gbps
switching engine that provides capacity for up to 32 nonblocking OC-3
155 ports or up to 8 nonblocking OC-12 622 Mbps ports. Using an
enhanced i960CF processor, the CoreBuilder 7000HD switch supports
expanded memory, higher performance LAN Emulation services and
faster signaling (up to 50% improvement over version 4.0). The switch
also accommodates scalable, high density Ethernet/ATM, Fast Ethernet
and Gigabit Ethernet interface cards. The four slot chassis allows for a
mixture of port types with versatile media options for a wide range of
network configurations.
Interface Module Type
155 Mbps OC3 fiber single-mode and multimode
interface modules
155 Mbps OC-UTP5 copper interface module
45 Mbps DS-3 module for WAN links
34 Mbps E-3 WAN interface
Three ATM interface modules; each can be either: 155
Mbps OC-3c fiber interface module or a 45 Mbps DS-3
module for WAN links
12 standard 10BaseT Ethernet connections
One ATM interface module; either a 155 Mbps OC-3c
fiber interface module or a 45 Mbps DS-3 module for
WAN links.
24/36 standard 10BaseT Ethernet connections
4 1000Base-FX connections
36 10/100 Base Tx Ports
