3Com CoreBuilder 7000 Management Manual page 324

C 11: C
324
HAPTER ONFIGURING
LAN E S
MULATION ERVERS
ELAN Parameters for Resident LESs
Table 47 ELAN Parameters for Resident LESs
Name Description
ELAN ID ELAN ID number.
ELAN Names ELAN name.
ELAN Type The type of frames that the ELAN recognizes:
802.3 Ethernet type
802.5 Token Ring type
Max Frame Size LAN Type
Ethernet
Fast Ethernet
Token Ring
FDDI
Control Specifies the point-to-multipoint connection ID between the
ELAN's BUS and the LECs, and the BUS member id. If no LECs
are connected, "no val" is displayed.
Mcast Specifies the point-to-multipoint connection between the
ELAN's BUS and the LECs, and the BUS member id. If no LECs
are connected, "no val" is displayed.
* supported by CB7000 HD only
† not typical
(LES) C
AND LIENTS
Frame Length (Bytes)
1516
1580
* : 1516
4544
† /4544
