C 7: C
210
HAPTER ONFIGURING

Signaling Timers

Display Protocol
Timer Resolution
V C
IRTUAL HANNELS
The following commands allow you to configure the ILMI signaling
timers.

Display Protocol Timer Resolution

Update Protocol Timer Resolution
Save Protocol Timer Resolution
Display UNI Signaling Timers
Display QSAAL Signaling Timers and SSCOP Configuration
For information about signaling timers, see "Signaling Timers" on page
111 in the Operations Guide.
Displays the current timer resolution in milliseconds for the UNI (Q93B)
and QSAAL protocol timers.
Each signaling protocol comes with a set of timers, one for each type of
message in the protocol. These timers determine when an expected
response to a message is overdue. They are set to the expected response
time when the message is sent and decrement towards zero. If they reach
zero before the response is received, the system is notified that the
response is overdue.
All the timers in the Q93B and QSAAL protocol are based on a common
timer tick-length called the timer resolution . When the timer resolution is
changed, all the signaling timers are affected.
The CoreBuilder 7000 family ATM switch is shipped with a default timer
resolution of 500 msec (0.5 secs). To change the value of an individual
timer, change the timer resolution proportionally. For example, if you
want to lower the "no response" timer from 50 secs to 25 secs, reduce
the timer resolution from 500 msec to 250 msec. Then the "no response"
timer, together with all the other timers, are reduced by one half. For
more information, see "Timer Resolution" on page 113 in the Operations
Guide.
