Display Signaling Protocol Profile - 3Com CoreBuilder 7000 Management Manual

C 7: C
200
HAPTER ONFIGURING
Display Signaling
Protocol Profile
V C
IRTUAL HANNELS
Displays the current signaling protocol profile for the specified port.
The signaling protocol profile of a port defines the role that the port plays
in the signaling dialog with its attached device. It can be Network or User.
When the port is connected to an end-station or edge device, the port is
normally defined as Network; when it is connected to another switch, it is
defined automatically as User or Network depending on their network
prefixes. For more information, see "Signaling Protocol Profile" on page
107 in the Operations Guide.
The Network port is the one which defines the VPI/VCI pair for the ATM
connection.
Command Actions
Enter the menu sequence: (1) SYS: Platform config
Direct access sequence:
Command Result
System action taken:
System message display:
Example
Enter:
1 1 5 1
The following information is displayed.
refers to a User profile.
Usr
(1) SET: Switch setup
(4) SIG: Signaling setup
(5) SPS: Signaling protocol setup
(1) GPR: Get profiles of ports
1 1 4 5 1
The current signaling protocol profile is displayed for
all ports.
Information is displayed as shown in the example
below.
refers to a Network profile;
Net
