2 Select the configuration data you want to download from disk from a list
of the data types displayed. Enter
File Types:
Select File type: 1
3 Enter the TFTP server IP address:
4 Enter the name of file (without an extension) on the server that contains
the data to be downloaded:
The configuration parameters are downloaded from seven different files
with sequential file extensions: switch/cfg/24_7_cfg.1 to
switch/cfg/24_7_cfg.7
5 The success status of the downloaded files is displayed as follows:
Load process of file type X completed successfully
Downloading System Software and Configuration
to upload all configuration data:
1
1<All>
2<Box Profile>
3<ATM Addresses>
4<PNNI Configuration>
5<LANE Security>
6<PVC Connections>
7<LECS Topology>
8<LECS Order List>
9<Other>
100.0.0.111
switch/cfg/24_7_cfg
53
