DATA SHEET
A versatile, multilayer
modular switching
platform for mid-range
Enterprise applications,
delivering highly
secure, resilient access
to business resources.
3Com
OVERVIEW
The 3Com
®
Switch 7750 Family of modular LAN switches provides
intelligent, multilayer switching and routing for enterprises and mid-
market businesses, enabling end-to-end network connectivity with
advanced traffic management. Providing unparalleled investment
protection with high scalability and performance, advanced security
and granular network control, the Switch 7750 Family delivers wirespeed
Fast Ethernet and Gigabit Ethernet connectivity with 10-Gigabit Ethernet
uplinks in a highly flexible and resilient modular platform.
The Switch 7750 Family is perfectly suited to networking environments
requiring non-stop access to critical business applications. Three chassis
models are available, providing a range of port densities and media
flexibility:
›
3Com Switch 7758—8-slot chassis with two slots for switch fabrics
(primary and redundant) and six slots supporting any combination
of switching I/O modules, up to 292 10/100/1000 or 288 10/100 ports
›
3Com Switch 7757—7-slot chassis with one slot for the switch fabric
and six slots supporting any combination of switching I/O modules,
up to 292 10/100/1000 or 288 10/100 ports
›
3Com Switch 7754—4-slot chassis with one slot for the switch fabric
and three slots supporting any combination of switching I/O modules,
up to 148 10/100/1000 or 144 10/100 ports.
All chassis models share the same high-performance, scalable modular
architecture—scaling up to 240 Gigabits per second (Gbps) system
bandwidth and 179 Million packets per second (Mpps) forwarding
performance—for maximum long term investment protection.
®
Switch 7750 Family
Advertisement
Table of Contents
Related Manuals for 3Com 3C16863A
Summary of Contents for 3Com 3C16863A
- Page 1 I/O modules, up to 292 10/100/1000 or 288 10/100 ports › 3Com Switch 7757—7-slot chassis with one slot for the switch fabric and six slots supporting any combination of switching I/O modules, up to 292 10/100/1000 or 288 10/100 ports ›...
-
Page 2: Key Benefits
KEY BENEFITS INTELLIGENT ENTERPRISE INFRASTRUCTURE Enterprise network infrastructure is evolving dramatically, from the core to the edge of the network, and the 3Com Switch 7750 is designed to meet the greater demands being placed on the entire network system to deliver: ›... - Page 3 SNMP v3 with authentication and encryption of network management traffic—are enforced when accessing switch management utilities. The Switch 7750 Family functions as an integral part of the 3Com Quarantine Protection solution to automate containment of security threats on the enterprise network. Quarantine Protection integrates the industry-leading TippingPoint switch-based endpoint enforcement at the network edge.
- Page 4 3Com has designed the Switch 7750 with an open architecture, facilitating seamless growth and migration based on widely accepted international standards, free from costly lock-ins and the restrictions of proprietary approaches.
- Page 5 IS-IS routing for enhanced support of legacy environments. * Redundant fabric available on Switch 7758 only. † Available in the 3Com Advanced Feature Software, at additional cost. AGGREGATE SYSTEM CAPACITIES Chassis slots Available slots (switch fabric and I/O)
- Page 6 3COM ® SWITCH 7750 FAMILY SAMPLE CONFIGURATION: DISTRIBUTION/EDGE DEPLOYMENT OF SWITCH 7750 FAMILY IN ENTERPRISE CAMPUS NETWORK LAN Controlle r WX4400 Wireless 3CRWX44 0095A...
- Page 7 SAMPLE CONFIGURATION: CORE-TO-EDGE DEPLOYMENT OF SWITCH 7750 FAMILY IN MID-SIZE ENTERPRISE NETWORK 3COM ® SWITCH 7750 FAMILY NBX V3000 NBX V3000 3Com 3Com 3Com 3Com NBX V3000 NBX V3000 NBX V3000...
-
Page 8: Service And Support
3Com Express 3Com University For additional information, please visit 3Com Global Services offers the resources and talents of a major corporation plus more than two decades of experience in resolving network challenges and delivering business benefits to enterprises around the world. -
Page 9: Specifications
Queuing algorithms Strict Priority Queuing (SPQ) † Available in the 3Com Advanced Feature Software, at additional cost. ‡ SNMP v3 and SSH v2 encryption features are available in the Basic Software with Encryption and Advanced Feature Software versions only. 3COM ®... - Page 10 IT environments • 3Com Network Director for comprehensive, turn-key network management for the enterprise • 3Com Network Supervisor for basic, turn-key network management for ‡ mid-market businesses ‡ AVAILABLE SWITCH FABRICS 96 Gbps Switch Fabric...
-
Page 11: Warranty
Information (SMI v1)) RFC 1157 (SNMP v1/v2c) RFC 1213 (MIB II) ‡ SNMP v3 and SSH v2 encryption features are available in the Basic Software with Encryption and Advanced Feature Software versions only. 3COM ® SWITCH 7750 FAMILY IMMUNITY EN 55024: 1998... -
Page 12: Ordering Information
Express are service marks, of 3Com Corporation or one of its subsidiaries. All other company and product names may be trademarks of their respective companies. While every effort is made to ensure the information given is accurate, 3Com does not accept liability for any errors or mistakes which may arise. All specifications are subject to change without notice.
