Signaling Setup 187
Example
Enter:
1 1 4 3 2 3.1.2 1 0
The following message appears:
This operation will release all connections of the specified
port(s)!
Are you sure (Y/N)?
Enter to confirm, to cancel.
Y N
The following message is displayed:
Parameter was successfully set.
The maximum VPI for port 3.1.2 is updated to 10.
Display Signaling
Display the current signaling protocol profile for the specified port.
Protocol Profile
The signaling protocol profile of a port defines the role that the port plays
in the signaling dialog with its attached device. It can be Network, User,
or Gateway.
The CoreBuilder 9000 ATM Enterprise Switch Gateway = IISP.
When the port is connected to an end station or edge device, the port is
normally defined as Network; when it is connected to another switch, it is
defined automatically as User or Network depending on their network
prefixes. The Gateway profile is set manually; one side as network and
the other side as user. (For more information, see "Signaling Protocol
Profile" on page 358.)
The Network port is the one that defines the VPI/VCI pair for the ATM
connection.
