Warning type

Warnings detected by the Simple Motion module include system warnings, axis warnings and warnings detected by servo
amplifier.
Simple Motion module detection system warnings
• System control data setting warnings: An axis warning for axis 1 will occur.
• Positioning data setting warnings: An axis warning for each axis will occur. Note that a warning will occur for the reference
axis when an interpolation designation or axis setting warning occurs.
Simple Motion module detection axis warnings
• Axis warnings that occur at operation start or during operation such as the positioning operation, JOG operation or manual
pulse generator operation.
• Axis warnings that occur due to system warnings: The axis operation status does not change even though an axis warning
occurs.
Servo amplifier detection warnings
The warnings that occur when the hardware error of the servo amplifier or servo motor occurs or the servo parameter is
inapplicable.
The servo may not be turned off depending on the warning. However, an error occurs or the operation cannot be executed
normally if the warning is remained.
When the warning cause is removed, the warning is automatically released in the servo amplifier. However, the state that the
warning occurs is continued in the Simple Motion module.
Reset it as necessary.

Warning code classification

Item
Warning code
Warnings
0900H to 093FH
0980H to 098FH
0990H to 09EFH
09F0H to 09FFH
0A10H to 0A5FH
0BA0H to 0BDFH
0BE0H to 0C3FH
0C40H to 0C7FH
0C80H to 0CBFH

Warning storage

When an axis warning occurs, the warning code corresponding to the warning details is stored in "[Md.24] Axis warning No.".
When an axis warning occurs in a positioning operation, etc., axis warning detection ([Md.31] Status: b9) for axis status
storage turns ON.
When a warning occurs on servo amplifier, the warning No. displayed in LED of servo amplifier is stored in "[Md.114] Servo
alarm". Check the warning details and remedies with "[Md.114] Servo alarm".
Warning detection signal
[Md.31] Status: b9
*1 A new warning code is stored in "[Md.24] Axis warning No." every time a warning occurs.
For the synchronous encoder axis, "b5: Warning detection flag" of "[Md.325] Synchronous encoder axis status" for target axis
turns ON, and the input axis warning number is stored in "[Md.327] Synchronous encoder axis warning No.".
14 TROUBLESHOOTING
14.3 Error and Warning Details
Classification of warnings
Positioning control common warnings
JOG, inching and manual pulse generator operation warnings
Positioning operation warnings
Block start data warnings
Positioning data warnings
Synchronous control input axis warnings
Synchronous control output axis warnings
Cam data operation warnings
Warnings for servo amplifier, amplifier manufactured by other companies, and head module
Warning code
*1
[Md.24] Axis warning No.
Servo alarm
[Md.114] Servo alarm
