[Pr.116] to [Pr.119] FLS/RLS/DOG/STOP signal selection

Set the input type whose external input signal (upper/lower limit signal (FLS/RLS), near-point dog signal (DOG) or stop signal

(STOP)) is used.

0 (0000H): Simple Motion module (Uses the external input signal of the Simple Motion module.)

1 (0001H): Servo amplifier

2 (0002H): Buffer memory (Uses the buffer memory of the Simple Motion module.)

15 (000FH): Invalid (Does not use the external input signal.)

*1 The setting is not available in "[Pr.119] STOP signal selection". If it is set, the error "STOP signal selection error" (error code: 1AD3H)

occurs and the PLC READY signal [Y0] is not turned ON.

*2 When it is set in "[Pr.116] FLS signal selection" to "[Pr.118] DOG signal selection" at MR-JE-B use, any errors or warnings do not occur.

However, the external input signal (upper/lower limit signal, near-point dog signal) cannot be operated.

■Input terminal

When the input type is set with "0: Simple Motion module", set the input terminal. The setting is not required when the value

other than "0" is set.

00H: No setting (The control by the external input signal is disabled.)

01H to 0AH: Set the input terminal.

• [RD77MS4/RD77MS8/RD77MS16]

01H to 14H: Set the input terminal.

Setting value

12 DATA USED FOR POSITIONING CONTROL

12.3 Basic Setting

(Uses the external input signal of the servo amplifier.)

Input terminal

Setting value

Input terminal
