The following shows the relation between the buffer memory addresses of servo parameter and the various items.
The setting range is different depending on the servo amplifier model. Refer to each servo amplifier instruction manual for
details.
n: Axis No. - 1
Memory area
Servo network composition parameters
Servo parameters
Item Servo amplifier parameter No.

[Pr.100] Connected device

PA01

PA02

PA03

PA04

PA05

PA06

PA07

PA08

PA09

PA10

PA11

PA12

PA13

PA14

PA15

PA16

PA17

PA18

PA19

PA20

PA21

PA22

PA23

PA24

PA25

PA26

PA27

PA28

PA29

PA30

PA31

PA32

PB01

PB02

PB03

PB04

PB05

PB06

PB07

PB08

PB09

PB10

PB11

PB12

PB13

PB14

PB15
Buffer memory address
58020+32n
58021+32n
28401+100n
28402+100n
28403+100n
28404+100n
28405+100n
28406+100n
28407+100n
28408+100n
28409+100n
28410+100n
28411+100n
28412+100n
28413+100n
28414+100n
28415+100n
28416+100n
28417+100n
28418+100n
64464+70n
64400+70n
64401+70n
64402+70n
64403+70n
64404+70n
64405+70n
64406+70n
64407+70n
64408+70n
64409+70n
64410+70n
64411+70n
64412+70n
28419+100n
28420+100n
28421+100n
28422+100n
28423+100n
28424+100n
28425+100n
28426+100n
28427+100n
28428+100n
28429+100n
28430+100n
28431+100n
28432+100n
28433+100n
