Warning code
Warning name
(Hexadecimal)
0A10H
Outside command
speed range
0C80H
Driver warning
0C81H
Incompatible device
0CC0H
Inter-module
synchronization
cycle time over
*1 When the torque change function is used with the individual setting for new torque value and reverse new torque value, it indicates
outside forward new torque value.
*2 This speed is a value in which override value is considered when override function is used. ("[Cd.13] Positioning operation speed
override" is set other than 100 [%].)
*3 The speed change by position-speed switching control, target position change function, or override function is contained.
*4 The speed change by position-speed switching control or target position change function is contained.
Error details and causes
• The speed change value is outside the setting range
when changing the speed during operation
• "[Cd.140] Command speed at speed control mode" is
outside the setting range during the speed control
mode.
• "[Cd.146] Speed limit value at torque control mode" is
outside the setting range during the torque control
mode.
[Operation status at warning occurrence]
• The speed change value is controlled as the
"maximum value within the setting range".
• The "[Md.39] In speed limit flag" is turned ON.
Warnings occur in the driver.
[Operation status at warning occurrence]
The operation continues.
Incompatible device is connected.
[Operation status at warning occurrence]
The operation continues.
The calculation process time of the inter-module
synchronous interrupt (I44) exceeds the internal
operation process time of the Simple Motion module.
[Operation status at warning occurrence]
The operation continues.
Remedy
• Set the speed change value to within the setting
*4
range.
• Set "[Cd.140] Command speed at speed control
mode" to within the setting range during the speed
control mode.
• Set "[Cd.146] Speed limit value at torque control
mode" to within the setting range during the torque
control mode.
Confirm the warning code by "[Md.114] Servo alarm"
and refer to the driver instruction manual for details.
Please contact with our sales representative.
Set the operation time longer.
Review the number of steps of the inter-module
synchronous interrupt (I44) to be short.
14 TROUBLESHOOTING
14.4 List of Warning Codes
14
587
