Avaya DEFINITY Server CSI Maintenance Manual page 144

Maintenance for CSI systems
Q.93B (Network) Layer
Are connection requests being received by A500 Call Control?
1. Enter show signaling stats port q93b (or the port of interest) on the A500
console.
A500:show signaling stats a1.2 q93b
-------------------------Q.93B Statistics------------------------
Port A1.2:
----------
Connect Messages:
Setup Messages:
Release Messages:
Rel Cmplt Messages:
Add Party Messages:
Add Party Acks:
Add Party Rejects:
Drop Party Messages:
Drop Party Acks:
Last Cause Code:
Last Diag Code:
Total Connections:
Current Connections:
Screen 38. A500:show signaling stats A1.2 q93b
Ensure that the fields have the values indicated below.
Port
A1.2
(or the port
of interest)
Connect
Messages
Setup
Messages
Release
Messages
144
Issue 5 October 2002
Screen 38 shows the screen output.
Tx Rx
-------- --------
15 18
18 15
17 13
13 17
0
0
0
0
0
31 31
0. 0. 0 71. 0.29
33
3
NOTE:
If there is no connection between the TN230X and the A500 at the
Q93B protocol layer, no report appears.
If this field is not configured for UNI signaling,
then the port was administered for no UNI signaling
(admin link command). Use the show signaling
summary command to verify that Signaling is UNI3.1.
These counters should be non-zero if the A500 is handling
Q.93B protocol layer messages sent by the PPN and
EPN. They may not increase during troubleshooting
unless calls are being made, since the PPN initially sets
up control connections to the PPN and then sets up talk
path connections as needed.
0
0
0
0
0
555-233-119
