YASKAWA CIPR-GA50C series Technical Manual page 318

10.5 Model Specifications (Three-Phase 400 V Class)
Model
Rated Output
*2
Capacity
(kVA)
Rated Output
Current (A)
Overload Tolerance
Output
Carrier Frequency
Maximum Output Voltage
Maximum Output Frequency
Measures for
DC reactor
Harmonics
Braking Device Braking Transistor
EMC Filter
EMC Filter
IEC61800-3
Rated Voltage/Rated Frequency
Permitted Voltage Fluctuation
Power Supply Permitted Frequency Fluctuation
Input Power
(kVA)
*1 The maximum applicable motor output complies with 380 V motor ratings as specified in Annex G of IEC 60947-4-1. The rated
output current of the drive output amps must be equal to or more than the motor rated current.
*2 The rated output capacity is calculated with a rated output voltage of 440 V.
318
Duty Rating 4018
HD 11.3
ND 13.3
HD 14.8
ND 17.5
• HD: 150% of the rated output current for 60 seconds. The permitted frequency of overload is once every 10
minutes.
• ND: 110% of the rated output current for 60 seconds. The permitted frequency of overload is once every 10
minutes.
Note:
Derating may be necessary for applications that start and stop frequently.
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Three-phase 380 V to 480 V
Note:
The maximum output voltage is proportional to the input voltage.
• V/f, OLV, OLV/PM: 590 Hz
• AOLV/PM: 270 Hz
• EZOLV: 120 Hz
External options
Standard internal characteristics
Factory option
Models 4xxxE: Category C2 (Conducted emission)
Three-phase AC power supply 380 V to 480 V at 50/60 Hz
-15% to +10%
±5%
14
HD
ND 18
4023 4031
13.7 18.3
17.8 23.6
18.0 24.0
23.4 31.0
18 27
22 35
YASKAWA SIEPC71061753A GA500 Technical Manual
4038 4044
23.6 29.7
29 33.5
31.0 39.0
38.0 44.0
36 47
40 55
4060
34.3
45.7
45.0
60
55
74
