Note:
The Single Drive KEB Ride-Thru 2 mode operates when L2-29 = 1 [KEB Method Selection = Single Drive KEB Ride-Thru 2] and H1-
xx = 7A or 7B [Terminal Sx Function Selection = KEB Ride-Thru 2 (N.C./N.O.)].
■
L3-35: Speed Agree Width for Auto Decel
No.
Name
(Hex.)
L3-35 Speed Agree Width for
Auto Decel
(0747)
Expert
Set this parameter when hunting occurs while you use a frequency reference through an analog input.
■
L3-36: Current Suppression Gain@Accel
No.
Name
(Hex.)
L3-36 Current Suppression
Gain@Accel
(11D0)
If there is vibration in the output current during acceleration, increase the setting value.
Note:
Set L3-01 = 3 [Stall Prevention during Accel = Current Limit Method] to enable this function.
■
L3-37: Current Limit P Gain @ Accel
No.
Name
(Hex.)
L3-37 Current Limit P Gain @
Accel
(11D1)
Expert
Note:
Set L3-01 = 3 [Stall Prevention during Accel = Current Limit Method] to enable this function.
■
L3-38: Current Limit I Time @ Accel
No.
Name
(Hex.)
L3-38 Current Limit I Time @
Accel
(11D2)
Expert
Note:
Set L3-01 = 3 [Stall Prevention during Accel = Current Limit Method] to enable this function.
■
L3-39: Current Limit Filter Time @Accel
No.
Name
(Hex.)
L3-39 Current Limit Filter Time
@Accel
(11D3)
Note:
Set L3-01 = 3 [Stall Prevention during Accel = Current Limit Method] to enable this function.
■
L3-40: Current Limit S-Curve @ Acc/Dec
No.
Name
(Hex.)
L3-40 Current Limit S-Curve @
Acc/Dec
(11D4)
YASKAWA SIEPC71061753A GA500 Technical Manual
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the width for speed agreement when L3-04 = 2 [Decel Stall Prevention Selection =
Automatic Decel Reduction]. Usually it is not necessary to change this setting.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the gain to suppress current and motor speed hunting during operation when L3-01 = 3 [Stall
Prevention during Accel = Current Limit Method]. Usually it is not necessary to change this
setting.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Suppresses current hunting during acceleration. Usually it is not necessary to change this setting.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Suppresses current hunting and overshooting that occurs when the drive stalls during acceleration.
Usually it is not necessary to change this setting.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the time constant to adjust the acceleration rate when L3-01 = 3 [Stall Prevention during
Accel = Current Limit Method]. Usually it is not necessary to change this setting.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets the function to enable and disable the best S-curve characteristic used for current-limited
acceleration.
12.9 L: Protection Functions
Description
Description
Description
Description
Description
Description
Default
(Range)
0.00 Hz
(0.00 - 1.00 Hz)
Default
(Range)
Determined by A1-02
(0.0 - 100.0)
Default
(Range)
5 ms
(0 - 100 ms)
Default
(Range)
10.0
(0.0 - 100.0)
Default
(Range)
100.0 ms
(1.0 - 1000.0 ms)
Default
(Range)
0
(0, 1)
