YASKAWA CIPR-GA50C series Technical Manual page 596

12.7 F: Options
■
F7-33 to F7-42: Dynamic In Param 1 to 10 for CommCard
No.
Name
(Hex.)
F7-33 - F7-42 Dynamic In Param 1 to 10
for CommCard
(0375 - 037E)
■
F7-60: PZD1 Write (Control Word)
No.
Name
(Hex.)
F7-60 PZD1 Write (Control Word)
(0780)
■
F7-61: PZD2 Write (Frequency Reference)
No.
Name
(Hex.)
F7-61 PZD2 Write (Frequency
Reference)
(0781)
■
F7-62: PZD3 Write
No.
Name
(Hex.)
F7-62 PZD3 Write
(0782)
■
F7-63: PZD4 Write
No.
Name
(Hex.)
F7-63 PZD4 Write
(0783)
■
F7-64: PZD5 Write
No.
Name
(Hex.)
F7-64 PZD5 Write
(0784)
■
F7-65: PZD6 Write
No.
Name
(Hex.)
F7-65 PZD6 Write
(0785)
■
F7-66: PZD7 Write
No.
Name
(Hex.)
F7-66 PZD7 Write
(0786)
596
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets Input Assembly 166. The drive sends the values from the MEMOBUS/Modbus address
registers stored for each parameter to Input Assembly 166. The drive returns the default register
value for the option card when the MEMOBUS/Modbus address is 0 and the value sent to Input
Assembly 166 is not defined.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the MEMOBUS/Modbus address for PZD1 (PPO output). PZD1 (PPO output) functions as
the STW when F7-60 = 0, 1, or 2.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets the MEMOBUS/Modbus address for PZD2 (PPO output). PZD2 (PPO output) functions as
the HSW when F7-61 = 0, 1, or 2.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets the MEMOBUS/Modbus address for PZD3 (PPO output). A value of 0, 1, or 2 will disable
the PZD3 (PPO output) write operation to the MEMOBUS/Modbus register.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the MEMOBUS/Modbus address for PZD4 (PPO output). A value of 0, 1, or 2 will disable
the PZD4 (PPO output) write operation to the MEMOBUS/Modbus register.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets the MEMOBUS/Modbus address for PZD5 (PPO output). A value of 0, 1, or 2 will disable
the PZD5 (PPO output) write operation to the MEMOBUS/Modbus register.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets the MEMOBUS/Modbus address for PZD6 (PPO output). A value of 0, 1, or 2 will disable
the PZD6 (PPO output) write operation to the MEMOBUS/Modbus register.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets the MEMOBUS/Modbus address for PZD7 (PPO output). A value of 0, 1, or 2 will disable
the PZD7 (PPO output) write operation to the MEMOBUS/Modbus register.
Description
Description
Description
Description
Description
Description
Description
Description
YASKAWA SIEPC71061753A GA500 Technical Manual
Default
(Range)
0
Default
(Range)
0
Default
(Range)
0
Default
(Range)
0
Default
(Range)
0
Default
(Range)
0
Default
(Range)
0
Default
(Range)
0
