No.
Name
(Hex.)
F6-55 DeviceNet Baud Rate
Monitor
(03C6)
F6-56 DeviceNet Speed
Scaling
(03D7)
F6-57 DeviceNet Current
Scaling
(03D8)
F6-58 DeviceNet Torque
Scaling
(03D9)
F6-59 DeviceNet Power
Scaling
(03DA)
F6-60 DeviceNet Voltage
Scaling
(03DB)
F6-61 DeviceNet Time Scaling
(03DC)
F6-62 DeviceNet Heartbeat
Interval
(03DD)
F6-63 DeviceNet Network
MAC ID
(03DE)
F6-64 to F6-67 Dynamic Out Assembly
109 Param 1 to 4
(03DF - 03E2)
F6-68 to F6-71 Dynamic In Assembly
159 Param 1 to 4
(03E3, 03E4,
03C7, and
03C8)
F6-72 PowerLink Node
Address
(081B)
◆

F7: Ethernet Options

No.
Name
(Hex.)
F7-01 IP Address 1
(03E5)
F7-02 IP Address 2
(03E6)
F7-03 IP Address 3
(03E7)
YASKAWA SIEPC71061753A GA500 Technical Manual
Description
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the function to see the actual DeviceNet communications speed using the keypad.
This parameter functions as a monitor only.
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the speed scale for DeviceNet communication.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the current scale of the DeviceNet communication master.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the torque scale of the DeviceNet communication master.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the power scale of the DeviceNet communication master.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets the voltage scale of the DeviceNet communication master.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets the time scale of the DeviceNet communication master.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the heartbeat for DeviceNet communication. Set this parameter to 0 to disable the
heartbeat function.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets the function to see the actual DeviceNet MAC address using the keypad. This
parameter functions as a monitor only.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets Configurable Outputs 1 to 4 written to the MEMOBUS register.
V/f OLV OLV/PM AOLV/PM EZOLV OLV/PM
Sets Configurable Inputs 1 to 4 written to the MEMOBUS register.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the node ID for PowerLink communication.
Note:
Be sure to set an address that is different than all other node addresses. Do not set
this parameter to 0.
Description
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the first octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Address Mode at Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 4] to set the IP Address. Be sure to set
a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the second octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Address Mode at Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 4] to set the IP Address. Be sure to set
a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
V/f OLV OLV/PM OLV/PM AOLV/PM EZOLV
Sets the third octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Address Mode at Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 4] to set the IP Address. Be sure to set
a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
11.9 F: Options
Default
Ref.
(Range)
0 590
(0 - 2)
0 591
(-15 - +15)
0 591
(-15 - +15)
0 591
(-15 - +15)
0 591
(-15 - +15)
0 591
(-15 - +15)
0 591
(-15 - +15)
0 591
(0 - 10)
0 591
(0 - 63)
0000h 591
(0000h - FFFFh)
0000h 592
(0000h - FFFFh)
0 592
(0 - 255)
Default
Ref.
(Range)
192 592
(0 - 255)
168 592
(0 - 255)
1 592
(0 - 255)
365
11
