MaverickCrunch Co-Processor
EP93xx User's Guide
Bit Definitions:
3
31:28
cond
Description:
Bit Definitions:
31:28 27:25
cond 1 1 0
Description:
3-22
N:
Rn:
CRd:
Loading Integer Value from Memory
27:25 24 23 22
1 1 0 P U N
Loads a 32- or 64-bit integer from memory into a MaverickCrunch register.

Table 3-12. Mnemonic Codes for Loading Integer Value from Memory

Mnemonic
CFLDR32<cond> CRd, [Rn, <offset>]{!}
CFLDR32<cond> CRd, [Rn], <offset>
CFLDR64<cond> CRd, [Rn, <offset>]{!}
CFLDR64<cond> CRd, [Rn], <offset>
N:
Rn:
CRd:
Store Floating Point Values to Memory
24 23 22 21
P U N W
Stores a single or double precision floating point value from a MaverickCrunch
register into memory.
Copyright 2007 Cirrus Logic
Floating point precision - 0 for single, 1 for double.
Base register in ARM
Destination register.
21 20 19:16 15:12
W 1 Rn CRd
Addressing Mode
Immediate pre-indexed
Immediate post-indexed
Immediate pre-indexed
Immediate post-indexed
Integer width - 0 for 32-bit integer, 1 for 64-bit integer
Base register in ARM
Destination register.
20 19:16 15:12
0 Rn CRd
11:8 7:0
0 1 0 1 8_bit_word_offset
N
0
0
1
1
11:8 7:0
0 1 0 0 8_bit_word_offset
DS785UM1
