CLK1HZ
V_SYNC
INT_VIDEO_FIFO Video FIFO Interrupt. See
INT_SSP1RX
INT_SSP1TX
TC3UI
INT_UART1
SSPINTR
INT_UART2
INT_UART3
USHINTR
INT_PME
DS785UM1
1 Hz clock interrupt. See
With Software Trim".
Vertical or Composite Sync/Frame Pulse Interrupt. See
Chapter 7, "Raster Engine With Analog/LCD Integrated
Timing and Interface".
Analog/LCD Integrated Timing and Interface"
SSP Receive Interrupt. See
Serial Port".
SSP Transmit Interrupt. See
Serial Port".
Timer Counter 3 Underflow Interrupt. This interrupt
becomes active on the next falling edge of the timer
counter 3 clock after the timer counter has under flowed
(reached zero). The interrupt is cleared by writing any
value to the "Timer3Clear"
"Timers".
UART 1 General Interrupt. This interrupt is active if any
UART1 interrupt is active. Interrupt service routines will
need to read the relevant status bits within UART1 to
determine the source of the interrupt. All these sources
are individually maskable within UART1. See
"UART1".
Synchronous Serial Port (SSP) Interrupt. See
"Synchronous Serial
UART 2 General Interrupt. This interrupt is active if any
UART2 interrupt is active. Interrupt service routines will
need to read the relevant status bits within UART2 to
determine the source of the interrupt. All these sources
are individually maskable within UART2. See
"UART2".
UART 3 General Interrupt. This interrupt is active if any
UART3 interrupt is active. Interrupt service routines will
need to read the relevant status bits within UART3 to
determine the source of the interrupt. All these sources
are individually maskable within UART3. See
"UART3 With HDLC
USB Host Interrupt. See
Controller".
PME interrupt. See
Port".
Copyright 2007 Cirrus Logic
Vectored Interrupt Controller
EP93xx User's Guide
Chapter 20, "Real Time Clock
Chapter 7, "Raster Engine With
Chapter 23 "Synchronous
Chapter 23 "Synchronous
register. See Chapter
Port".
Encoder".
Chapter 11, "USB Host
Chapter 23 "Synchronous Serial
6
18,
Chapter 15,
Chapter 23
Chapter 15,
Chapter 16,
6-7
