Universal Serial Bus Host Controller
EP93xx User's Guide
OpenHCI Implementation Specific Registers
The Root Hub partition contains registers that have power-on reset values that are
implementation specific. The values for the processor are indicated in the Default field for
each register, below.
HcRevision
11
31 30
15 14
Address:
Default:
Definition:
Bit Description:
HcControl
31 30
15 14
Address:
Default:
11-12
29 28 27 26
13 12 11 10
RSVD
0x8002_0000
0x0000_0010
Defines the revision of the OHCI specification with which this implementation
is compatible.
RSVD:
REV:
29 28 27 26
13 12 11 10
RSVD RWE
0x8002_0004
0x0000_0000
25 24 23 22
RSVD
9 8 7 6
Reserved. Unknown During Read.
This read-only field contains the BCD representation of the
version of the HCI specification that is implemented by this
HC.
0x10 = Compatible with OHCI 1.0.
25 24 23 22
RSVD
9 8 7 6
RWC IR HCFS
