Table 13-11. EP93xx SDRAM Address Ranges (16-Bit Wide Data Systems) (Continued)
Device
Size, Address
Organization
Type Matrix
System
512 Mbit (16-
13 x 10 x
bit wide
4 banks
device)
16-Bit Wide
Data Systems
(Continued)
SROMLL = 0
Total
Bank
Continuous Address
Size
Range (see Note)
0xN300_0000 - 0xN33F_FFFF
0xN400_0000 - 0xN43F_FFFF
0xN500_0000 - 0xN53F_FFFF
0xN600_0000 - 0xN63F_FFFF
0xN700_0000 - 0xN73F_FFFF
64
0xN800_0000 - 0xN83F_FFFF
Mbytes
0xN900_0000 - 0xN93F_FFFF
0xNA00_0000 - 0xNA3F_FFFF
0xNB00_0000 - 0xNB3F_FFFF
0xNC00_0000 - 0xNC3F_FFFF
0xND00_0000 - 0xND3F_FFFF
0xNE00_0000 - 0xNE3F_FFFF
0xNF00_0000 - 0xNF3F_FFFF
SROMLL = 1
Size of Continuous Address
Segment Range (see Note)
0xN000_0000 - 0xN07F_FFFF
0xN100_0000 - 0xN17F_FFFF
0xN200_0000 - 0xN27F_FFFF
0xN300_0000 - 0xN37F_FFFF
4 Mbytes 0xN400_0000 - 0xN47F_FFFF
0xN500_0000 - 0xN57F_FFFF
0xN600_0000 - 0xN67F_FFFF
0xN700_0000 - 0xN77F_FFFF
Size of
Segment
8 Mbytes
