Cirrus Logic EP93 Series User Manual page 587

Arm 9 embedded processor family
Table of Contents

Advertisement

TIS:
RIS:
MIS:
UART3LowPwrCntr
31
30
29
28
15
14
13
12
Address:
0x808E_0020 - Read/Write
Default:
0x0000_0000
Definition:
UART3 IrDA Low Power Divisor Register. This register is present in UART3
but is not supported.
Bit Descriptions:
RSVD:
UART3DMACtrl
31
30
29
28
15
14
13
12
Address:
0x808E_0028 - Read/Write
DS785UM1
Transmit Interrupt Status. This bit is set to 1 if the
UARTTXINTR transmit interrupt is asserted, which occurs
when the transmit FIFO is not full. It is set to 0 when the
transmit FIFO is full.
Receive Interrupt Status. This bit is set to 1 if the
UARTRXINTR receive interrupt is asserted, which occurs
when the receive FIFO is not empty. It is set to 0 when the
receive FIFIO is empty.
Modem Interrupt Status. This bit is set to 1 if the
UARTMSINTR modem status interrupt is asserted. This
bit is cleared by writing any value to this register.
27
26
25
24
RSVD
11
10
9
8
RSVD
Reserved. Unknown During Read.
27
26
25
24
RSVD
11
10
9
8
RSVD
Copyright 2007 Cirrus Logic
23
22
21
20
7
6
5
4
23
22
21
20
7
6
5
4
UART3 With HDLC Encoder
EP93xx User's Guide
19
18
17
16
3
2
1
0
19
18
17
16
3
2
1
0
DMAERR
TXDMAE
RXDMAE
16-11
16
