Cirrus Logic EP93 Series User Manual page 567

FE:
UART2LinCtrlHigh
31 30 29 28
15 14 13 12
Address:
0x808D_0008 - Read/Write
Default:
0x0000_0000
Definition:
UART - High. UART2LinCtrlHigh, UART2LinCtrlMid and UART2LinCtrlLow
form a single 23-bit wide register (UART2LinCtrl) which is updated on a single
write strobe generated by an UART2LinCtrlHigh write. So, in order to internally
update the contents of UART2LinCtrlMid or UART2LinCtrlLow, a
UART2LinCtrlHigh write must always be performed at the end.
To update the three registers there are two possible sequences:
• UART2LinCtrlLow write, UART2LinCtrlMid write and UART2LinCtrlHigh write
• UART2LinCtrlMid write, UART2LinCtrlLow write and UART2LinCtrlHigh
write.
To update UART2LinCtrlLow or UART2LinCtrlMid only:
•
write.
Bit Descriptions:
RSVD:
WLEN:
DS785UM1
Framing Error. When this bit is set to "1", it indicates that
the received character did not have a valid stop bit (a valid
stop bit is "1"). This bit is cleared to 0 by a write to
UART2RXSts. In FIFO mode, this error is associated with
the character at the top of the FIFO.
27 26 25
11 10 9
RSVD
UART2LinCtrlLow write (or UART2LinCtrlMid write) and UART2LinCtrlHigh
Reserved. Unknown During Read.
Number of bits per frame:
11 = 8 bits
10 = 7 bits
01 = 6 bits
00 = 5 bits
Copyright 2007 Cirrus Logic
24 23 22 21
RSVD
8 7 6 5
WLEN
UART2
EP93xx User's Guide
20 19 18 17
4 3 2 1
FEN STP2 EPS PEN
15
16
0
BRK
15-9
