IrDA
EP93xx User's Guide
Bit Descriptions:
IrDataTail
31
30
17
15
14
Address:
Default:
Definition:
Bit Descriptions:
17-28
DATA:
29
28
27
26
13
12
11
10
0x808B_0014, 0x808B_0018, 0x808B_001C - Write Only
0x0000_0000
IrDA Data Tail Register. This is a 24-bit write only register used for transmitting
frames whose payload data is not an integer multiple of 4 bytes long. The bit
locations are cleared when read by the transmit logic or when the TXE control
bit is clear. The IrData Tail register may be written using one of three
addresses. Bits two and three of the address determine how many bytes
within the word are significant, that is, are intended for transmission. If none of
the address is written, the register remains marked as empty and payload data
will be read by the transmit logic from the 32-bit FIFO only. The status of this
register does not affect the TFS flag, nor does it cause interrupts or DMA
requests to be generated.
RSVD:
DATA:
Copyright 2007 Cirrus Logic
IrDA data word. Values written and sent to the transmit
FIFO. Values read are from the receiver FIFO.
25
24
23
22
DATA
9
8
7
6
DATA
Reserved. Unknown During Read.
IrDA transmit payload data. Write to address 0x014, least
significant byte is transmitted. Write to address 0x018,
least significant two bytes are transmitted. Write to
address 0x01C, least significant three bytes are
transmitted.
21
20
19
18
5
4
3
2
17
16
1
0
DS785UM1
