Register Descriptions
Timer1Load,
Timer2Load
31 30 29 28
15 14 13 12
Address:
Timer1 - 0x8081_0000 - Read/Write
Timer2 - 0x8081_0020 - Read/Write
Reset Value:
0x0000_0000
Definition:
The Load register contains the initial value of the timer and is also used as the
reload value in periodic timer mode. The timer is loaded by writing to the Load
register when the timer is disabled. The Timer Value register is updated with
the Timer Load value as soon as the Timer Load register is written. The Load
register should not be written after the Timer is enabled because this causes
the Timer Value register to be updated with an undetermined value.
Bit Descriptions:
RSVD:
Load:
Timer3Load
31 30 29 28
15 14 13 12
Address:
Timer3 - 0x8081_0080 - Read/Write
Reset Value:
0x0000_0000
DS785UM1
27 26 25 24
RSVD
11 10 9 8
Load
Reserved. Unknown During Read.
Initial load value of the timer.
27 26 25 24
Load
11 10 9 8
Load
Copyright 2007 Cirrus Logic
23 22 21 20
7 6 5 4
23 22 21 20
7 6 5 4
Timers
EP93xx User's Guide
19 18 17 16
3 2 1 0
19 18 17 16
3 2 1 0
18-3
