HashTbl
9
63 62
47 46
31 30
15 14
Address:
Chip Reset:
Soft Reset:
Definition:
Bit Descriptions:
9-54
61 60 59 58
45 44 43 42
29 28 27 26
13 12 11 10
0x8001_0050 through 0x8001_0057 - 8 Bytes - Read/Write,
when AFP = 111b
0x0000_0000
Unchanged
Hash Table Register. The hash table is used as a way of filtering groups of
addresses in the receiver. Following the reception of the destination address
(first 6 bytes of a receive frame), the upper 6 bits of the computed CRC are
used as an address into the hash table. If the bit accessed by this address is a
"1", the frame passes the hash table test, if the bit is a "0", the frame fails the
hash table test.
The hash table may be used for either or both of individual addressed frames
and group address frames, depending on the IAHA and MA bits in RXCtl. A
frame has a group address if the first bit of the frame is a one.
If an individual address frame passes the hash test and the IAHA bit is set, the
frame passes the destination filter.
If a group address frame passes the hash test and the MA bit set, the frame
passes the destination filter.
HTb:
Copyright 2007 Cirrus Logic
57 56 55 54
HTb
41 40 39 38
HTb
25 24 23 22
HTb
9 8 7 6
HTb
Hash Table entries.
53 52 51 50
37 36 35 34
21 20 19 18
5 4 3 2
49 48
33 32
17 16
1 0
DS785UM1
