ColorLUT
31 30 29 28
15 14 13 12
Address: 0x8003_0400 through 0x8003_07FC
Default: Unknown after power up
Definition: Color Look-Up-Table
Bit Descriptions:
Note: Triple 8-bit RGB is the most common way to use the LUT. However, The LUT may be
organized differently depending on the needs of the display technology.
RSVD:
R, G, B:
Video Signature Registers
VidSigRsltVal
31 30 29 28
15 14 13 12
Address: 0x8003_0200
Default: 0x0000_0000
Definition: Video Output Signature Result Value register
DS785UM1
Raster Engine With Analog/LCD Integrated Timing and Interface
27 26 25
RSVD
11 10 9
G
Reserved - Unknown during read
Red, Green, Blue Color - Read/Write
Triple 8-bit Red, Green, and Blue Look-Up-Table (LUT)
data is written to and read from these LUT locations. The
position in the LUT where the RGB data is read/written is
determined by the word address value ADR[9:2]. When
the LUT is in the video pipeline, pixel data [23:0] is output
from LUT word location ADR[9:2].
27 26 25
11 10 9
Copyright 2007 Cirrus Logic
24 23 22 21
8 7 6 5
24 23 22 21
RSVD
8 7 6 5
SIGVAL
EP93xx User's Guide
20 19 18 17
R
4 3 2 1
B
20 19 18 17
4 3 2 1
7
16
0
16
0
7-77
