Address:
Timer3 - 0x8081_0084 - Read Only
Reset Value:
0x0000_0000
Definition:
The Value location gives the current value of the timer. When the Timer Load
register is written to, the Value register is also updated with this Load value.
Bit Descriptions:
Value:
Timer1Clear,
Timer2Clear,
Timer3Clear
31 30 29 28
15 14 13 12
Address:
Timer1 - 0x8081_000C - Write Only
Timer2 - 0x8081_002C - Write Only
Timer3 - 0x8081_008C - Write Only
Reset Value:
Not defined.
Definition:
Writing any value to the Clear location clears an interrupt generated by the
timer.
Bit Descriptions:
RSVD:
DS785UM1
Current value of the timer.
27 26 25 24
RSVD
11 10 9 8
RSVD
This register has no readable bits. It is just a write trigger.
Copyright 2007 Cirrus Logic
23 22 21 20
7 6 5 4
Timers
EP93xx User's Guide
19 18 17 16
3 2 1 0
