DiagDa
31 30 29 28
15 14 13 12
Address:
0x8001_003C - Read/Write
Chip Reset:
0x0000_0000
Soft Reset:
0x0000_0000
Definition:
Diagnostic Data Register. The Diagnostic Data Register provides access to
the internal register pointed to by the value in the Diagnostic Address register.
For debug only.
Bit Descriptions:
DATA:
GT
31 30 29 28
15 14 13 12
Address:
0x8001_0040 - Read/Write
Chip Reset:
0x0000_0000
Soft Reset:
0x0000_0000
Definition:
General Timer Register
DS785UM1
27 26 25 24
DATA
11 10 9 8
DATA
Internal register data value.
27 26 25 24
GTC
11 10 9 8
GTP
Copyright 2007 Cirrus Logic
1/10/100 Mbps Ethernet LAN Controller
23 22 21 20
7 6 5 4
23 22 21 20
7 6 5 4
EP93xx User's Guide
19 18 17 16
3 2 1 0
19 18 17 16
3 2 1 0
9-49
