Fr X25 Template - 3Com 3C13618 Command Reference Manual

3Com Router Command Reference Guide — V1.00
SVC 40, State: TRANSFER, Interface: Serial0
Connects: X.121 ietf <--> 102
Begin:1998-1-1 2:45:34, Last input time: 0:0:5, Last output time: 0:0:5
ip 1.1.1.2 cud pid, no Tx data PID
Window size: input 2 output 2
Packet Size: input 128 output 128
PS: 2 PR: 2 ACK: 2 Remote PR: 1 RCNT: 0
RNR: FALSE Reset times: 0
input/output: DATA 10/10 INTERRUPT 0/0 Bytes 840/840
Snd Queue: Current length 0 Max length 500 Drops 0
Rcv Queue: Current length 0 Max length 500 Drops 0
Table 5-4 The information of X.25 virtual circuit
Field
State
Interface
Connects
Begin
Last input time
Last output time
Window size
Packet Size
PS
PR
ACK
Remote PR
RCNT
RNR
REJ
Snd Queue
Current length
Max length
Drops
Rcv Queue

5.1.11 fr x25 template

Syntax
fr x25 template name
50
RR 0/0 RNR 0/0 REJ 0/0
The state of this virtual circuit
The interface that this virtual circuit belongs to.
The X.121 address of the remote end connected to the virtual circuit.
The time for establishing the virtual circuit.
The last time for receiving the packet.
The last time for sending the packet.
The size of X.25 windows.
The size of X.25 packet.
The sending number of local end.
The receiving number of local end.
The acknowledge number.
The receiving number of remote end.
The statistics of sending packets.
The times of overflowing of the receive windows.
The number of error packets rejected by remote end.
The sending queue of this virtual circuit.
The current length of queue.
The max length of queue.
The number of dropped packet because of the queue is full.
The recieving queue of this virtual circuit.
Meaning
