Constraint Faults - Intel i960 Jx Developer's Manual

8.10.2

CONSTRAINT Faults

Fault Type:
Fault Subtype:
Function:
RIP:
Fault IP:
Class:
Program State Changes:
Trace Reporting:
5H
Number Name
0H Reserved
1H RANGE
2H-FH Reserved
Indicates the program or procedure violated an architectural constraint.
A CONSTRAINT.RANGE fault is generated when a
instruction is executed and the AC register condition code field
matches the condition required by the instruction.
No defined value.
Faulting instruction.
Imprecise.
These faults may be imprecise when executing with the AC.nif bit
cleared. No changes in the program's control flow accompany these
faults. A CONSTRAINT.RANGE fault is generated after the
FAULT<cc> instruction executes. The program state is not affected.
Serviced upon return from the Constraint fault handler.
FAULTS
FAULT<cc>
8
8-23
