PVT SYSTEM

Assembly View

Snap Ring
1
Bearing
Stationary Sheave
Pin
Roller
Moveable Sheave
Clutch Shaft
5.36
10
11
12
13
14
48 in-lb (5 Nm)
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
Spring
Spider Insert
9
Spider Dampener
E-Clip
Washer
Helix (Cam)
Helix Screws
