WALKER EVANS™SHOCK ASSEMBLY VIEWS
Walker Evans™ 2.0" Front Shock
REF DESCRIPTION
Body Cap Asm.
1.
2.
Seal Head Asm.
Internal Bump Stop
3.
Shaft Bushing (0.625")
4.
O-Ring
5.
6.
Seal
Wiper
7.
O-Ring
8.
Piston, Clicker
9.
10.
Clicker Bolt
11.
Clicker Knob
12.
Clicker Stud
Screw (10/32")
13.
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
REF DESCRIPTION
Piston Asm, Floating (IFP)
14.
Reservoir End Cap
15.
Reservoir Body
16.
Washer (1.50" x 0.125" x
17.
0.348")
Crimp Nut (7/16")
18.
Snap Ring
19.
Spherical Bearing
20.
21.
Schraeder Valve
Snap Ring
22.
Piston Wear Band (1.750" OD) 36.
23.
Bump Stop
24.
25.
N/A
Shaft Loop
26.
© Copyright 2014 Polaris Industries Inc.
STEERING / SUSPENSION
REF DESCRIPTION
Shaft Spacer (1.235" x 1.985")
27.
O-Ring
28.
Screw (8/32")
29.
O-Ring
30.
O-Ring
31.
Detent Spring
32.
33.
Detent Ball
Shock Body
34.
Spring Adjustment Nut
35.
Shaft, Chrome
37.
2-Piece Piston Asm.
8
8.29
