Vehicle Speed Display - Analog display of vehicle speed in MPH or km/h.
1
Information Display Area - Odometer / Trip Meter / Tachometer / Engine Temperature / Engine Hours
/ Service Info / Clock - LCD display of the service hour interval, total vehicle miles or km., total engine
hours, a trip meter, engine RPM and engine temperature.
MPH / KM/H Display - MPH is displayed when the instrument cluster is in the Standard mode. KM/H is
displayed when the instrument cluster is in the Metric mode.
High Beam Indicator - LED icon illuminates whenever the Headlamp switch is in the high beam position.
Fuel Level Indicator - LCD bar graph indicating current fuel level. All segments will flash when the fuel
level is very low.
Clock - Displays current time in either 12-hour or 24-hour formats.
Engine Temperature Indicator - LED icon illuminates when the ECM determines the engine is
overheating. The indicators will initially flash to indicate the engine is overheating. The indicators will stay lit
and not flash if a severe overheating condition exists.
Service Interval Indicator - Preset at the factory and adjustable by the user, a flashing wrench symbol
alerts the operator that the preset service interval has been reached and maintenance should be
performed. The wrench icon will flash for 10 seconds upon start-up once it reaches 0.
Check Engine MIL - Illuminated when the ECM has detected a Diagnostic Trouble Code in the engine
9
management system.
AWD Indicator - Illuminated when the AWD / 2WD switch is in the AWD position.
10
Differential Unlocked Indicator - If equipped with Turf Mode, will illuminate when the AWD switch is in
11
Turf mode..
Neutral Gear Indicator - LED icon illuminates when gear selector is in the neutral (N) position.
12
Gear Position Indicator - Displays gear selector position.
P = Park
R = Reverse
N = Neutral
13
D = Drive
3 = 3rd Gear
2 = 2nd Gear
1 = 1st Gear
– = Gear Signal Error (shifter stuck between gears)
Power Steering System MIL - LED icon illuminates when a fault has occurred in the EPS system. This
14
indicator also turns on momentarily when the key is turned on.
Turn Signal / Hazard Lamp Indicator - If equipped with turn signals, the LED icon illuminates whenever
15
the left, right or hazard blinker is activated.
Helmet / Seat Belt Indicator - LED icon illuminates for several seconds when the key is turned to the ON
position as a reminder for the riders to properly use safety equipment. The lamp stays illuminated until the
16
driver's seat belt is properly latched.
Hours Indicator - Illuminates when Hours are being displayed on the Information Display
17
Mode Button - Used to move through the menu features.
18
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
ELECTRICAL
11
11.5
