ENGINE / COOLING SYSTEM

Cooling System Bleeding Procedure

WARNING
Always wear safety glasses and proper shop clothing
when performing the procedures in this manual. Failing
to do so may lead to possible injury or death.
CAUTION
Use caution when performing these procedures.
Coolant may be hot and may cause
severe injury or burns.
NOTE: If the coolant level is LOW in the radiator, or
if there are leaks in the system, the coolant system
will not draw coolant from the reservoir tank.
1. Allow engine and cooling system to cool down.
CAUTION
Be sure the engine has cooled and no pressure is built
up in the cooling system before removing the pressure
cap. The coolant may be hot and could cause severe
injury or burns.
2. Remove the hood.
3. Remove the recovery bottle cap
to the MAX line.
4. Remove the pressure cap
amount of Polaris Premium Antifreeze to the radiator
filler neck.
5. Remove the seats, engine service panel and divider
panel heat shield to access the coolant bleed screw.
3.18
and fill the bottle
1
and add the necessary
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
6. Open the bleed screw
escape. Close the bleed screw once a steady stream
of coolant begins to drain out.
7. Tighten the bleed screw to specification, top off
coolant and properly install the pressure cap.
Coolant Bleed Screw:
89 in-lb (10 Nm)
8. Start the engine and allow it to idle until the coolant
fan has cycled two times.
9. Allow engine and cooling system to completely cool
down (see CAUTION).
10. Remove the pressure cap. Add the necessary
amount of Polaris Premium Antifreeze to the radiator
filler neck.
11. Open the bleed screw to allow any trapped air to
escape. Close the bleed screw once a steady stream
of coolant begins to drain out.
12. Tighten the bleed screw to specification, top off
coolant and properly install the pressure cap.
Coolant Bleed Screw:
89 in-lb (10 Nm)
13. Fill the recovery bottle to the MAX line.
14. Reinstall the hood.
15. Reinstall the seats and engine service panel.
to allow any trapped air to
