GENERAL INFORMATION

Special Tools

PART NUMBER TOOL DESCRIPTION
Fluke™ 77 Digital Multimeter
PV-43568
PV-43526
Connector Test Kit
Timing Light
2870630
Battery Hydrometer
PU-50338
2460761
Hall Effect Sensor Probe Harness
Static Timing Light Harness
2871745
Battery Conductance Analyzer
PU-50296
(MDX-610P)
Relay Bypass
PU-49466
Digital Wrench® (see Chapter 4 –
-
DIGITAL WRENCH® OPERATION,
page 4.46)
Bosch Automotive Service Solutions: 1-800-345-
2233 or http://polaris.service-solutions.com/
2015 RZR Torque Specifications
ITEM
Coolant Temperature
Sensor
Starter Mounting
Fasteners
Oxygen Sensor
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
TORQUE
17 ft-lb (23 Nm)
7 ft-lb (10 Nm)
13 ft-lb (18 Nm)
© Copyright 2014 Polaris Industries Inc.

Electrical Service Notes

Keep the following notes in mind when diagnosing an
electrical problem:
• Refer to wiring diagram for stator and electrical
component resistance specifications.
• When measuring resistance of a component that
has a resistance value under 10 Ohms, remember
to subtract meter lead resistance from the reading.
Connect the leads together and record the
resistance. The resistance of the component is
equal to tested value minus the lead resistance.
• Become familiar with the operation of your meter.
Be sure leads are in the proper jack for the test
being performed (i. e. 10A jack for current
readings). Refer to the Owner's Manual included
with your meter for more information.
• Voltage,
amperage,
included in this manual are obtained with a
Fluke™ 77 Digital Multimeter (PV-43568). This
meter
is
used
problems. Readings obtained with other meters
may differ.
• Pay attention to the prefix on the multimeter
reading (K, M, etc.) and the position of the decimal
point.
• For resistance readings, isolate the component to
be tested. Disconnect it from the wiring harness or
power supply.

Under-Dash Components

The following switches and components can be
accessed underneath the instrument / dash panel:
• Speedometer
• AWD Switch
• Headlamp Switch
• 12 Vdc Accessory Power Point
• Ignition Switch
• LED Ambiance Light
ELECTRICAL
and
resistance
values
when
diagnosing
electrical
