Cooling System Assembly View

Thermostat housing
1
Water Pump
Engine Hoses
Lower Radiator Hose
Fan Assembly
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
Filler Neck
Radiator
Pressure Cap
Upper Radiator Hose
9
Recovery Bottle
10
© Copyright 2014 Polaris Industries Inc.
ENGINE / COOLING SYSTEM
Oil Cooler Inlet Hose
11
Oil Cooler Outlet Hose
12
Bypass Hose
13
Water Pump Outlet Hose
14
