General-purpose I/Os (GPIO)
7.4.2

GPIO port output type register (GPIOx_OTYPER)

(x = A..I)
Address offset: 0x04
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
OT15 OT14 OT13 OT12
rw rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 OTy[1:0]: Port x configuration bits (y = 0..15)
7.4.3

GPIO port output speed register (GPIOx_OSPEEDR)

(x = A..I/)
Address offset: 0x08
Reset values:
● 0x0000 00C0 for port B
●
0x0000 0000 for other ports
31 30 29
OSPEEDR15[1:0] OSPEEDR14[1:0] OSPEEDR13[1:0] OSPEEDR12[1:0] OSPEEDR11[1:0] OSPEEDR10[1:0] OSPEEDR9[1:0] OSPEEDR8[1:0]
rw rw rw
15 14 13
OSPEEDR7[1:0] OSPEEDR6[1:0] OSPEEDR5[1:0] OSPEEDR4[1:0]
rw rw rw
Bits 2y:2y+1 OSPEEDRy[1:0]: Port x configuration bits (y = 0..15)
7.4.4

GPIO port pull-up/pull-down register (GPIOx_PUPDR)

(x = A..I/)
Address offset: 0x0C
199/1422
27 26 25
11 10 9
OT11 OT10 OT9
rw rw rw
These bits are written by software to configure the output type of the I/O port.
0: Output push-pull (reset state)
1: Output open-drain
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
These bits are written by software to configure the I/O output speed.
00: 2 MHz Low speed
01: 25 MHz Medium speed
10: 50 MHz Fast speed
11: 100 MHz High speed on 30 pF (80 MHz Output max speed on 15 pF)
Doc ID 018909 Rev 4
24 23 22 21
Reserved
8 7 6 5
OT8 OT7 OT6 OT5
rw rw rw rw
24 23 22
rw rw rw
8 7 6
OSPEEDR3[1:0] OSPEEDR2[1:0] OSPEEDR1[1:0] OSPEEDR0[1:0]
rw rw rw
20 19 18
4 3 2
OT4 OT3 OT2
rw rw rw
21 20 19 18
rw rw rw rw
5 4 3 2
rw rw rw rw
RM0090
17 16
1 0
OT1 OT0
rw rw
17 16
rw rw
1 0
rw rw
