System configuration controller (SYSCFG)
Bits 31:2 Reserved, must be kept at reset value.
8.2.2 SYSCFG peripheral mode configuration register (SYSCFG_PMC)

for STM32F405xx/07xx and STM32F415xx/17xx

Address offset: 0x04
Reset value: 0x0000 0000
31 30 29
15 14 13
Bits 31:24 Reserved, must be kept at reset value.
Bits 22:0 Reserved, must be kept at reset value.
8.2.3 SYSCFG peripheral mode configuration register (SYSCFG_PMC)

for STM32F42xxx and STM32F43xxx

Address offset: 0x04
Reset value: 0x0000 0000
31 30 29
15 14 13
207/1422
Bits 1:0 MEM_MODE: Memory mapping selection
Set and cleared by software. This bit controls the memory internal mapping at
address 0x0000 0000. After reset these bits take the value selected by the Boot
pins (except for FSMC).
00: Main Flash memory mapped at 0x0000 0000
01: System Flash memory mapped at 0x0000 0000
10: FSMC Bank1 (NOR/PSRAM 1 and 2) mapped at 0x0000 0000
11: Embedded SRAM (112kB) mapped at 0x0000 0000
28 27 26 25
Reserved
12 11 10 9
Bit 23 MII_RMII_SEL: Ethernet PHY interface selection
Set and Cleared by software.These bits control the PHY interface for the
Ethernet MAC.
0: MII interface is selected
1: RMII Why interface is selected
Note: This configuration must be done while the MAC is under reset and before
enabling the MAC clocks.
28 27 26 25
Reserved
12 11 10 9
Doc ID 018909 Rev 4
24 23 22 21
MII_RMII
_SEL
rw
8 7 6 5
Reserved
24 23 22 21
MII_RMII
_SEL
Reserved
rw
8 7 6 5
Reserved
RM0090
20 19 18 17
Reserved
4 3 2 1
20 19 18 17
ADC3D ADC2D
C2 C2
rw rw
4 3 2 1
16
0
16
ADC1D
C2
rw
0
