DMA controller (DMA)
9.5.5

DMA stream x configuration register (DMA_SxCR) (x = 0..7)

This register is used to configure the concerned stream.
Address offset: 0x10 + 0x18 × stream number
Reset value: 0x0000 0000
31
30
29
Reserved
15
14
13
PINCOS
MSIZE[1:0]
rw
rw
rw
Bits 31:28 Reserved, must be kept at reset value.
Bits 27:25 CHSEL[2:0]: Channel selection
These bits are set and cleared by software.
000: channel 0 selected
001: channel 1 selected
010: channel 2 selected
011: channel 3 selected
100: channel 4 selected
101: channel 5 selected
110: channel 6 selected
111: channel 7 selected
These bits are protected and can be written only if EN is '0'
Bits 24:23 MBURST: Memory burst transfer configuration
These bits are set and cleared by software.
00: single transfer
01: INCR4 (incremental burst of 4 beats)
10: INCR8 (incremental burst of 8 beats)
11: INCR16 (incremental burst of 16 beats)
These bits are protected and can be written only if EN is '0'
In direct mode, these bits are forced to 0x0 by hardware as soon as bit EN= '1'.
Bits 22:21 PBURST[1:0]: Peripheral burst transfer configuration
These bits are set and cleared by software.
00: single transfer
01: INCR4 (incremental burst of 4 beats)
10: INCR8 (incremental burst of 8 beats)
11: INCR16 (incremental burst of 16 beats)
These bits are protected and can be written only if EN is '0'
In direct mode, these bits are forced to 0x0 by hardware.
Bits 20 Reserved, must be kept at reset value.
Bits 19 CT: Current target (only in double buffer mode)
This bits is set and cleared by hardware. It can also be written by software.
0: The current target memory is Memory 0 (addressed by the DMA_SxM0AR pointer)
1: The current target memory is Memory 1 (addressed by the DMA_SxM1AR pointer)
This bit can be written only if EN is '0' to indicate the target memory area of the first transfer.
Once the stream is enabled, this bit operates as a status flag indicating which memory area
is the current target.
239/1422
28
27
26
25
CHSEL[3:0]
rw
rw
rw
12
11
10
9
PSIZE[1:0]
MINC
PINC
rw
rw
rw
rw
Doc ID 018909 Rev 4
24
23
22
21
MBURST [1:0]
PBURST[1:0]
rw
rw
rw
rw
8
7
6
5
CIRC
DIR[1:0]
PFCTRL
rw
rw
rw
rw
20
19
18
DBM or
CT
Reserv
reserved
ed
rw
rw or r
4
3
2
TCIE
HTIE
TEIE
DMEIE
rw
rw
rw
RM0090
17
16
PL[1:0]
rw
rw
1
0
EN
rw
rw
