Advanced-control timers (TIM1&TIM8)
1. When both outputs of a channel are not used (CCxE = CCxNE = 0), the OISx, OISxN, CCxP and CCxNP bits must be kept
cleared.
Note: The state of the external I/O pins connected to the complementary OCx and OCxN
channels depends on the OCx and OCxN channel state and the GPIO registers.
14.4.10 TIM1&TIM8 counter (TIMx_CNT)
Address offset: 0x24
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 CNT[15:0]: Counter value
14.4.11 TIM1&TIM8 prescaler (TIMx_PSC)
Address offset: 0x28
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 PSC[15:0]: Prescaler value
14.4.12 TIM1&TIM8 auto-reload register (TIMx_ARR)
Address offset: 0x2C
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 ARR[15:0]: Auto-reload value
413/1422
12 11 10 9
rw rw rw rw
12 11 10 9
rw rw rw rw
The counter clock frequency (CK_CNT) is equal to f
PSC contains the value to be loaded in the active prescaler register at each update event
(including when the counter is cleared through UG bit of TIMx_EGR register or through
trigger controller when configured in "reset mode").
12 11 10 9
rw rw rw rw
ARR is the value to be loaded in the actual auto-reload register.
Refer to Section 14.3.1: Time-base unit on page 356
and behavior.
The counter is blocked while the auto-reload value is null.
Doc ID 018909 Rev 4
8 7 6 5
CNT[15:0]
rw rw rw rw
8 7 6 5
PSC[15:0]
rw rw rw rw
CK_PSC
8 7 6 5
ARR[15:0]
rw rw rw rw
for more details about ARR update
4 3 2 1
rw rw rw rw
4 3 2 1
rw rw rw rw
/ (PSC[15:0] + 1).
4 3 2 1
rw rw rw rw
RM0090
0
rw
0
rw
0
rw
