Hash Status Register (Hash_Sr) - ST STM32F40 Series Reference Manual

RM0090
22.4.7

HASH status register (HASH_SR)

Address offset: 0x24
Reset value: 0x0000 0001
31 30 29
15 14 13
Bits 31:4 Reserved, forced by hardware to 0.
28 27 26 25
12 11 10 9
Reserved
Bit 3 BUSY: Busy bit
0: No block is currently being processed
1: The hash core is processing a block of data
Bit 2 DMAS: DMA Status
This bit provides information on the DMA interface activity. It is set with DMAE
and cleared when DMAE=0 and no DMA transfer is ongoing. No interrupt is
associated with this bit.
0: DMA interface is disabled (DMAE=0) and no transfer is ongoing
1: DMA interface is enabled (DMAE=1) or a transfer is ongoing
Bit 1 DCIS: Digest calculation completion interrupt status
This bit is set by hardware when a digest becomes ready (the whole message
has been processed). It is cleared by writing it to 0 or by writing the INIT bit to 1
in the HASH_CR register.
0: No digest available in the HASH_Hx registers
1: Digest calculation complete, a digest is available in the HASH_Hx registers.
An interrupt is generated if the DCIE bit is set in the HASH_IMR register.
Bit 0 DINIS: Data input interrupt status
This bit is set by hardware when the input buffer is ready to get a new block (16
locations are free). It is cleared by writing it to 0 or by writing the HASH_DIN
register.
0: Less than 16 locations are free in the input buffer
1: A new block can be entered into the input buffer. An interrupt is generated if
the DINIE bit is set in the HASH_IMR register.
Doc ID 018909 Rev 4
24 23 22 21
Reserved
8 7 6 5
Hash processor (HASH)
20 19 18 17
4 3 2 1
BUSY DMAS DCIS
r r rc_w0
16
0
DINIS
rc_w0
620/1422
