Analog-to-digital converter (ADC)

11.13.17 ADC common regular data register for dual and triple modes

(ADC_CDR)

Address offset: 0x08 (this offset address is relative to ADC1 base address + 0x300)
Reset value: 0x0000 0000
31 30 29 28
r r r
15 14 13 12
r r r
Bits 31:16 DATA2[15:0]: 2nd data item of a pair of regular conversions
– In dual mode, these bits contain the regular data of ADC2. Refer to
– In triple mode, these bits contain alternatively the regular data of ADC2, ADC1 and ADC3.
Bits 15:0 DATA1[15:0]: 1st data item of a pair of regular conversions
– In dual mode, these bits contain the regular data of ADC1. Refer to
– In triple mode, these bits contain alternatively the regular data of ADC1, ADC3 and ADC2.

11.13.18 ADC register map

The following table summarizes the ADC registers.
Table 54. ADC global register map
Offset
0x000 - 0x04C
0x050 - 0x0FC
0x100 - 0x14C
0x118 - 0x1FC
0x200 - 0x24C
0x250 - 0x2FC
0x300 - 0x308
307/1422
27 26 25
r r r r
11 10 9
r r r r
Refer to Triple ADC mode.
Refer to Triple ADC mode.
Doc ID 018909 Rev 4
24 23 22 21
DATA2[15:0]
r r r r
8 7 6 5
DATA1[15:0]
r r r r
Register
ADC1
Reserved
ADC2
Reserved
ADC3
Reserved
Common registers
20 19 18 17
r r r r
4 3 2 1
r r r r
Dual ADC mode.
Dual ADC mode
RM0090
16
r
0
r
